APLEX AEx series is the solution for hazardous environments. It is capable of withstanding vibration, shock, and corrosion and can operate under conditions of exposure to gas, vapor, powder, and dust.
The AEx series comes in panel PC (AEx-8XXP/9XXAP), display (AEx-1XXP) and box PC (AEx-2410/2411) which are packed with different levels of computing performance required in the harshest environment applications.
15.6" TFT-LCD, Full HD (1920x1080), 400 nits brightness, 16.2M colours, 50,000-hour backlight life
Touch Screen
Projected capacitive, >90% light transmission
Processor
Intel 6th Gen Core i3/i5 (fanless design)
Memory
1 x SO-DIMM DDR4 slot, up to 16GB DDR4 2133MHz
Storage
1 x 2.5" HDD/SSD slot, 1 x mSATA slot
I/O Ports
- 2 x M12 8-pin LAN (with waterproof covers)
- 1 x M12 3-pin DC power connector (waterproof)
- 1 x M12 8-pin VGA (waterproof)
- 1 x M12 8-pin COM (RS-232/422/485, default RS-232, waterproof)
- 2 x USB 2.0 (M12 connectors with waterproof covers)
Expansion
1 x Mini-PCIe (full size)
Power Input
DC 9-36V
Construction
316 stainless steel chassis
Dimensions
440 x 290 x 75 mm
Weight
10 kg
Mounting Options
VESA mount (100x100) and optional panel mount
Environmental Ratings
IP66-rated on all six sides, ATEx/IECEx-certified for hazardous zones
Certifications
ATEx Zone 2/22, IECEx Zone 2/22, CE, FCC Class A, ANSI/ISA 12.12-01-2013
Operating Temperature
-20°C to 60°C
Operating System
Windows Embedded 7/8.1, Windows 10 IoT ENT LTSB
Description
APLEX AEx series is the solution for hazardous environments. It is capable of withstanding vibration, shock, and corrosion and can operate under conditions of exposure to gas, vapor, powder, and dust.
The AEx series comes in panel PC (AEx-8XXP/9XXAP), display (AEx-1XXP) and box PC (AEx-2410/2411) which are packed with different levels of computing performance required in the harshest environment applications.
