CEM841 - Celeron J1900

A$0.00

In stock

COM Express Type 2 Basic Module with Intel® Celeron® Processor J1900/N2807

Intel® Celeron® processor J1900/N2807 (Bay Trail)

2 SO-DIMM DDR3L-1066/1333 up to 8GB

Max. up to 8 lanes of PCIe

1 SATA-300 and 1 IDE

8 USB 2.0

Brand

Axiomtek

Specifications

CPU	Intel® Celeron® processor J1900 2 GHz or Celeron® N2807 1.58 GHz onboard
Chipset	SoC integrated
System Memory	2 x SO-DIMM DDR3L-1066/1333, up to 8 GB
BIOS	AMI
Serial	N/A
USB	8 x USB 2.0
Ethernet	1 x 10/100/1000 Mbps (Intel® i210AT)
Display	1 x VGA 1 x LVDS
GPIO	4-IN & 4-OUT
Audio	HD link interface to baseboard for Codec
Storage	1 x SATA-300
Expansion	1 x PCIe x4 4 x PCIe x1 (or 3 x PCIe x1 while internal LAN is connected)
Others	1 x LPC interface 1 x IDE
Battery	N/A
Power Input	ATX: +12V and 5VSB or AT: +12V
Watchdog Timer	255 levels, 1~255 sec. or min.
Hardware Monitoring	Yes
Operating Temperature	0°C ~ +60°C (32°F ~ 140°F)
Relative Humidity	10% ~ 95% relative humidity, non-condensing
Dimensions	125 x 95 mm
Board Thickness	2.0 mm
Certifications	CE

Description

Intel® Celeron® processor J1900/N2807 (Bay Trail)

2 SO-DIMM DDR3L-1066/1333 up to 8GB

Max. up to 8 lanes of PCIe

1 SATA-300 and 1 IDE

8 USB 2.0
