CF220I - 128MB - 8GB Compact flash card

A$0.00

In stock

Ruggedized and featuring excellent temperature flexibility while delivering top performance, Transcend's CF220I Industrial Temp CF cards are specifically designed for industrial use and mission-critical applications.

Details

Compliant with CompactFlash specification 6.0

Compliant with RoHS 2.0 standards

Enhanced S.M.A.R.T. function for durability

Security Command

Global Wear-Leveling and Block management for reliability

Static Data Refresh

Early Retirement

Erase Count Monitoring

Operation Modes: PC Card Memory, PC Card IO, True IDE

More Information

Specifications

Appearance
Dimensions	42.8 mm x 36.4 mm x 3.3 mm (1.69" x 1.43" x 0.13")
Pin	50 pin
Form Factor	Compact flash card
Storage
Flash Type	SLC NAND flash
Capacity	128 MB/ 256 MB/ 512 MB/ 1 GB/ 2 GB/ 4 GB/ 8 GB
Operating Environment
Operating Voltage	3.3V±5% 5V±10%
Operating Temperature	-40°C (-40°F) ~ 85°C (185°F)
Storage Temperature	-55°C (-67°F) ~ 100°C (212°F)
Humidity	0% ~ 95%
Shock	Acceleration: 490 m/s² (standard holding time: 11 ms, semi-sine wave, velocity change: 3.44 m/s)
Vibration (Operating)	20 G (peak-to-peak), 20 Hz ~ 2,000 Hz (frequency)
Power
Power Consumption (Max.)	0.54 watt(s)
Performance
Read Speed (Max.)	56 MB/s
Write Speed (Max.)	44 MB/s
Mean Time Between Failures (MTBF)	3,000,000 hour(s)
Note	Speed may vary due to host hardware, software, usage, and storage capacity.
Warranty
Warranty	Three-year Limited Warranty
