DSB320, Celeron J1900, AVB support

A$0.00

In stock

SKU

DSB320-842

Fanless Digital Signage Player with Intel® Celeron® Processor J1900 up to 2.42 GHz

Fanless Digital Signage Player with Intel® Celeron® Processor J1900 up to 2.42 GHz

· Fanless operation

· Low power consumption

· Intel® Celeron® 4-core J1900 onboard (Bay Trail-D)

· DDR3L-1333 SO-DIMM, up to 8GB

· 1 HDMI/1 VGA with dual independent displays supported

· 1 mSATA supported

· Supports AVB (Audio Video Bridging) feature

· Supports TV rack, wall mount and VESA mount

Brand

Axiomtek

Specifications

CPU	Intel® Celeron® processor J1900 up to 2.42 GHz (Bay Trail)
Chipset	SoC Integrated
System Memory	1 x 204-pin SO-DIMM DDR3L-1333, up to 8 GB
Watchdog Timer	255 levels, 1 ~ 255 sec
COM	1 x RS-232
USB	4 x USB 2.0
Ethernet	1 x 10/100/1000 Mbps (Intel® i210AT)
Display	1 x HDMI 1 x VGA
Audio	Line out/Mic-in
Storage	1 x mSATA
Expansion	1 x Full-size PCI Express Mini Card (for mSATA ) 1 x Half-size PCI Express Mini Card with SIM slot
Others	1 x 8-CH TTL DIO 1 x Remote button switch 1 x Kensington lock Wi-Fi antenna (optional)
Wi-Fi	Optional 802.11 b/g/n
Power Supply	12VDC, with AC-DC 12/36W Adapter
Vibration Endurance	N/A
Operating Temperature	0°C ~ +40°C (32°F ~ 113°F)
Dimensions (W x D x H)	180.7 x 128 x 34.7 mm (7.11” x 5.04” x 1.37”)
Weight (net/gross)	1 kg (2.21 lb)/ 1.5 kg (3.3 lb)
Mounting	Wall mount VESA mount
EOS Support	Windows® 7, Windows® 8.1, Windows® 10
Software Support	N/A
Certifications	CE

Description

Fanless Digital Signage Player with Intel® Celeron® Processor J1900 up to 2.42 GHz

· Fanless operation

· Low power consumption

· Intel® Celeron® 4-core J1900 onboard (Bay Trail-D)

· DDR3L-1333 SO-DIMM, up to 8GB

· 1 HDMI/1 VGA with dual independent displays supported

· 1 mSATA supported

· Supports AVB (Audio Video Bridging) feature

· Supports TV rack, wall mount and VESA mount
