DSP600, AMD V1000, Quad Display media player
4K Digital Signage Player with AMD Ryzen Embedded V1000 Series, 4 HDMI, 2 GbE LAN and 4 USB
· AMD Ryzen Embedded V1000 series
· 2 x DDR4-2400 SO-DIMM for up to 32GB of memory
· 4 x HDMI 2.0 with 4K resolution
· 4 x USB, 2 GbE LAN
· 1 x M.2 Key E 2230 for Wi-Fi/BT
· 2 x M.2 Key M 2280 for storage
More Information
| Brand |
Axiomtek |
| Specifications |
| CPU | - AMD Ryzen Embedded Quad Core V1807B/V1605B and Dual core V1202B onboard
| | Chipset | | | System Memory | - 2 x DDR4-2400 SO-DIMM, up to 32GB
| | Watchdog Timer | - 255 levels, 1 to 255 sec./min.
| | COM | | | USB | | | Ethernet | | | Display | - 4 x HDMI 2.0 (4K supported)
| | Audio | | | Storage | - 1 x M.2 Key M 2280 (SATA)
- 1 x M.2 Key M 2280 (NVMe)
| | Expansion | - 1 x M.2 Key E for Wi-Fi/BT
- 1 x M.2 Key B for 4G/LTE
- 1 x SIM card slot
| | Others | - 1 x Device management
- 1 x HDD LED
- 1 x Power switch
- 1 x Reset switch
- 1 x Remote switch
- 4 x Antenna opening
- TPM 2.0
| | Wi-Fi | - 1 x M.2 Key E for Wi-Fi/BT
- 1 x M.2 Key B for 4G/LTE
- 1 x SIM card slot
| | Power Supply | | | Vibration Endurance | - 3 Grms with M.2 storage (5 - 500Hz, X, Y, Z directions)
| | Operating Temperature | - 0ºC to +45ºC (32ºF to +113ºF)
| Dimensions
(W x D x H) | - 250 x 182.8 x 30mm (9.84” x 7.19” x 1.18”)
| | Weight (net/gross) | - 1.9 kg (4.18 lb)/2.9k g (6.39 lb)
| | Mounting | | | EOS Support | | | Software Support | | | Certifications | | |
| Description |
· AMD Ryzen Embedded V1000 series · 2 x DDR4-2400 SO-DIMM for up to 32GB of memory · 4 x HDMI 2.0 with 4K resolution · 4 x USB, 2 GbE LAN · 1 x M.2 Key E 2230 for Wi-Fi/BT · 2 x M.2 Key M 2280 for storage |
