Shop eBOX565-52R-FL Fanless Embedded System

Details

The eBOX565-52R-FL is a fanless embedded box powered by an Intel Core i5-8365UE/Celeron 4305UE Processor with HDMI and DisplayPort++ display I/O, and 2 LAN and COM ports. The systems also has 9-36VDC power input allowing for vehicle use.

Features

8th gen Intel® Core™ and Celeron® processor onboard (Whisky Lake-U )
One M.2 Key E 2230 for Wi-Fi module
260-pin DDR4-2400 SO-DIMM, max. up to 32GB
2 GbE LAN and 2 USB 3.1 Gen2
Supports DisplayPort++ and HDMI for dual independent displays
Multiple mounting designs: Wall mount, DIN-rail and VESA mount
9 to 36 VDC wide-range input

More Information

Brand

Axiomtek

Specifications

CPU	Intel® Core™ i5-8365UE, 1.6 GHz Intel® Celeron® 4305UE, 2.0 GHz
Chipset	SoC integrated
System Memory	1 x 260-pin DDR4-2400 SO-DIMM, up to 32GB
BIOS	AMI
COM	2 x RS-232/422/485
USB	2 x USB 2.0 2 x USB 3.1 Gen2
Ethernet/PoE	2 x 10/100/1000 Mbps Ethernet (Intel® i219-LM, Intel® i211-AT)
Display	1 x DisplayPort++ 1 x HDMI (lockable)
Digital I/O	N/A
Audio	N/A
Storage	1 x 2.5" SATA HDD drive bay (max. up 9.5 mm height)
Expansion	1 x M.2 Key E 2230 (for Wi-Fi)
Others	1 x ATX power switch 1 x AT/ATX quick switch 1 x Screw type VDC power input connector 2 x Antenna opening 1 x Phoenix type VDC power input connector
Power	9 - 36 VDC
Watchdog Timer	65535 levels, 1 to 65536 sec.
Construction	Aluminium extrusion and heavy-duty steel, IP40
Operating Temperature	-10°C to +50°C (+14°F to +122°F) with 0.7 m/s airflow (with W.T. SSD/DRAM)
Relative Humidity	10% - 90%, non-condensing
Vibration	IEC 60068-2-64 (with SSD: 3Grms STD, random, 5 to 500 Hz, 1 hr/axis)
Shock	IEC 60068-2-27 (with SSD: 50G, half sine, 11 ms duration)
Dimensions (W x D x H)	141.6 x 106 x 73 mm (5.57" x 4.17" x 2.87")
Weight (net/gross)	1.1 kg (2.43 lb)/1.8 kg (3.96 lb)
Certifications	CE, FCC Class A
EOS Support	Win 10 IoT, Linux
Software Support	AMS.AXView
Mounting	DIN-Rail kit VESA mount kit Wall mount kit

Description

The eBOX565-52R-FL is a fanless embedded box powered by an Intel Core i5-8365UE/Celeron 4305UE Processor with HDMI and DisplayPort++ display I/O, and 2 LAN and COM ports. The systems also has 9-36VDC power input allowing for vehicle use.

Features

8th gen Intel® Core™ and Celeron® processor onboard (Whisky Lake-U )
One M.2 Key E 2230 for Wi-Fi module
260-pin DDR4-2400 SO-DIMM, max. up to 32GB
2 GbE LAN and 2 USB 3.1 Gen2
Supports DisplayPort++ and HDMI for dual independent displays
Multiple mounting designs: Wall mount, DIN-rail and VESA mount
9 to 36 VDC wide-range input
