The FX30 is the industry’s smallest, most rugged programmable 3G/4G LTE cellular gateway. Providing an integrated, secure embedded application environment, tightly integrated with the cloud, scalable and global deployments of IoT applications for any connected machine or infrastructure.
INTERFACES UART FX30S only: Configurable RS232/RS485 Sub-D9 USB USB V2.0 Micro-B connector LEDs 1 signal LED, 1 user LED I/Os 3 configurable I/Os Audio PCM (on IoT Connector) Push button For user app (GPIO) SIM interface 2FF Embedded SIM MFF2 (optional) Cellular Antenna SMA GNSS Antenna SMA with active bias HARDWARE EXTENSION 1xIoT Connector (1xUSB, 1xUART, 1xSPI, 1xI2C, 4xGPIO, 1xADC, 1xSDIO, 1xPCM) MOUNTING OPTIONS Bracket for screw/wall and DIN rail mounting LOCATION SERVICES A-GPS, GLONASS, GALILEO CONTROL OPTIONS AT Commands, Legato® shell, Legato® applications
