| Specifications |
CAMERA
Lens 2.9mm (140.5° x 120.2° x 65.3°)
Image Sensor 1/2.7” 2.1Megapixel Progressive CMOS Sensor
Number of Effective Pixels 1920(H) x 1080(V) approx. 2.0M pixels
Min. Illumination
Color Mode: 0.2 Lux
B/W Mode: 0.02 Lux
Scanning Mode Progressive Scan
Day and Night Mode Automatic, Day, Night,
8 IR LED
Auto Exposure Mode Automatic, Manual
Shutter Speed Control 1/25 ~ 1/10,000
Auto White Balance Mode Automatic, Manual
Digital Zoom Yes by on-screen
Back Light Compensation OFF/HLC/BLC/WDR( <30FPS )
DNR OFF/LOW/MIDDLE/HIGH
Image Effect Mirror, Flip
Privacy Mask 1 Area Selection
Video Motion Detection 1 Area Selection (8 *10=80 AREA) NETWORK
Video Compression H.264(Base line profile)
Video Resolution
(30fps@1920*1080P)
H.264 - Primary : 1920 x1080, 1280x720, 800x600, 704x480,
704x400, 640x480
H.264 secondary 640x480, 320x240
Video Resolution
(60fps@1280*720P)
(WDR not used)
H.264 - Primary : 1280*720P, 640x480, 320x240
H.264 secondary 640x480, 320x240
Video Streaming H.264/H.264 Dual Streaming
Login Authority Administrator, Operator, Viewer
Security ID/Password
Network Time Sync Synchronize Computer/NTP Server, Manual
Remote Upgrade Using Web Browser
Protocols TCP/IP, UDP, IPv4, HTTP, UPnP, RTP, RTSP, RTCP, DHCP
Client Software Built-In Web, ONVIF Compatible 3rd Party VMS
Max. User Connection 4 Users
SDK Support CGI Command, ONVIF Compliant
OPERATION ENVIRONMENTS
Operating Humidity 0~80% (non-condensing)
Operating Temperature -30℃~ +60℃
PoE Support
DC12V Optional
Power Consumption 1.6W
Lens Shading ON/OFF
ACE OFF/LOW/MIDDLE/HIGH
Motion ON/OFF
Audio G.711 |
