i59U, i5-6200U, 2.5" SATA + mSATA + M.2
Skylake main-stream signage player, Intel 6th generation core processor
Skylake main-stream signage player, Intel 6th generation core processor
· Intel 6th generation core processor
· 1 x SO-DIMM DDR3L,Up to 32GB
· 1 x DP,1 x HDMI, Supporting 4K Display
· 1 x 2.5” SATA, 1 x mSATA, 1 x M.2, 1 x TF Card
· 1 x USB 3.0 Type-C, 2 x USB3.0, 2 x USB2.0, 1 x RS232
· 2 x RJ45,1 x Mini-PCIe for WiFi/BT/3G/4G, 1 x SIM Slot
· Supports Intel vPro Technology (Optional)
More Information
| Brand |
Giada Technology Inc. |
| Specifications |
| |
i59U-B3000 |
i59U-B5000 |
| Processor |
CPU |
Intel®Core™ i3-6100U |
Intel®Core™ i5-6200U |
| Frequency |
2.30GHz (Up to 2.80GHz) |
2.30GHz (Up to 2.80GHz) |
| BIOS |
AMI Source Code |
| Chipset |
SOC |
| Memory |
Type |
DDR3L-1600MHz |
| Socket |
2 x SO-DIMM |
| Max Size |
32GB |
| Graphics |
GPU |
Intel® HD Graphics 520 |
| Graphic Engine |
Direct3D 2015, OpenGL 4.5, OpenCL 2.1 |
| DP |
1 x DP (Max.4096 x 2304 @60Hz) |
| HDMI |
1 x HDMI (Max.3840x2160 @30Hz) |
| Network |
Controller |
Intel® I219LM Gigabit Ethernet |
| Interface |
1 x RJ45 |
| I/O |
USB |
1 x USB 3.0 Type-C,2 x USB 3.0,2 x USB 2.0 |
| Serial Port |
1 x RS232 |
| Audio |
1 x MIC-IN，1 x AUDIO-OUT&SPDIF |
| Mini-PCIe 1# |
1 x Full-size Mini-PCIe for mSATA |
| Mini-PCIe 2# |
1 x Full-size Mini-PCIe for WiFi/BT/3G/4G |
| M.2(2230) |
1 x M.2(2242/2280) for SSD |
| SIM |
1 x SIM Slot |
| Storage |
SATA |
1 x 2.5"SATA |
| mSATA |
1 x Full-size mSATA |
| M.2 |
1 x M.2 |
| TF Card |
1 x TF Card Reader |
| JAHC Tech |
WatchDog Timer |
0~255 Second Time Out Support |
| Auto Power On |
Power Activated Automatically Start |
| Remote Control |
By IR Controller for Power On |
| RTC |
Set Up Independently Every day, A Week as a Cycle |
| Operation System |
Windows |
Windows 7/8.1/10（64-Bit） |
| Linux |
Supported |
| Power |
Power Type |
DC-IN |
| Input Voltage |
19V / 3.42A |
| Mechanical |
Dimensions (W × D × H) |
189.6mm x 148.3mm x 26mm（7.46"x 5.84"x 1.02"） |
| Construction |
Metal |
| Mounting |
Desk/Wall Mounting and VESA Mounting Kit (JZ183) |
| Color |
Black |
| Environment |
Operating Temperature |
0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow |
| Relative Humidity |
95%@40℃ (non-condensing) |
| Certification |
Certification |
CE, FCC Class B, CCC |
|
| Description |
Skylake main-stream signage player, Intel 6th generation core processor
· Intel 6th generation core processor
· 1 x SO-DIMM DDR3L,Up to 32GB
· 1 x DP,1 x HDMI, Supporting 4K Display
· 1 x 2.5” SATA, 1 x mSATA, 1 x M.2, 1 x TF Card
· 1 x USB 3.0 Type-C, 2 x USB3.0, 2 x USB2.0, 1 x RS232
· 2 x RJ45,1 x Mini-PCIe for WiFi/BT/3G/4G, 1 x SIM Slot
· Supports Intel vPro Technology (Optional)
|
