IES-150B 5 port unmanaged switch
5x10/100Base-T(X) port supported by compact design and wide operating temperature range from -40°C to 70°C.
- Supports 5 ports 10/100 Base-T(X)
- Supports auto-negotiation and auto-MDI/MDI-X
- Supports store-and-forward transmission
- Supports flow control
- Compact size for easily installation
- Rigid IP-30 housing design
- DIN-Rail and wall mounting enabled
More Information
| Specifications |
| Physical Ports | | | 10/100Base-T(X) Ports in RJ45 Auto MDI/MDIX | 5 | | Technology | | | Ethernet Standards | IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3x for Flow control | | MAC Table | 1K | | Packet Buffer | 448Kbits | | Processing | Store-and-Forward | | Switch Properties | Switch latency: <7us
Switch bandwidth: 1Gbps
Throughput(packet per second): 0.744Mpps@64Bytes packet | | LED Indicators | | | Power Indicator | Green : Power LED x 2 | | 10/100Base-T(X) RJ45 port Indicator | Green for port Link/Act.
Lower LED for speed indicator: Amber for 100Mbps, OFF-light for 10Mbps | | Power | | | Input Power | Dual 12~48 VDC and 24VAC on 4-pin terminal block | | Power Consumption (Typ.) | <3Watts, 12-48VDC: 0.10A-0.04A, 24VAC (50/60Hz) 0.10A | | Overload Current Protection | Present | | Reverse Polarity Protection | Present | | Physical Characteristics | | | Enclosure | IP-30 | | Dimensions (W x D x H) | 26.1 (W) x 70 (D) x 95 (H)mm (1.027 x 2.755 x 3.74 inch) | | Weight (g) | 205 g | | Hardware Version | v3.0 | | Environmental | | | Storage Temperature | -40 to 85°C (-40 to 185°F) | | Operating Temperature | -40 to 75°C (-40 to 167°F) | | Operating Humidity | 5% to 95% Non-condensing | | Regulatory Approvals | | | EMC | CE EMC (EN 55024, EN 55032), FCC Part 15 B | | EMI | EN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A | | EMS | EN 55024 (IEC/EN 61000-4-2 (ESD: Contact 4KV, Air 8KV), IEC/EN 61000-4-3 (RS: 3V),IEC/EN 61000-4-4 (EFT Power 0.5KV, Signal 0.5KV), IEC/EN 61000-4-5 (Surge: Power 0.5KV, Signal 1KV), IEC/EN 61000-4-6 (CS: 3V), IEC/EN 61000-4-8(PFMF), IEC/EN 61000-4-11 (DIP)) | | Shock | IEC60068-2-27 | | Free Fall | IEC60068-2-31 | | Vibration | IEC60068-2-6 | | Safety | IEC 60950-1, UL 60950-1, EN 60950-1 (LVD), UL61010-1, UL61010-2-201 | | Others | E-MARK | | MTBF | 2,638,236hrs | | Warranty | 5 years | |
| Description |
- Supports 5 ports 10/100 Base-T(X)
- Supports auto-negotiation and auto-MDI/MDI-X
- Supports store-and-forward transmission
- Supports flow control
- Compact size for easily installation
- Rigid IP-30 housing design
- DIN-Rail and wall mounting enabled
|
