IES-180B - 8 port mini type unmanaged switch
8x10/100Base-T(X) ports, IES-180B is with rigid IP-30 housing design and features extended operating temperature range from -40 oC to 75 oC.
- Supports 8 ports 10/100 Base-T(X)
- Supports auto-negotiation and auto-MDI/MDI-X
- Supports store and forward transmission
- Supports flow control
- Compact size for easily installation
- Rigid IP-30 housing design
- DIN-Rail and wall mounting enabled
More Information
| Specifications |
| Physical Ports | | | 10/100Base-T(X) Ports in RJ45 Auto MDI/MDIX | 8 | | Technology | | | Ethernet Standards | IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3x for Flow control | | MAC Table | 1K MAC addresses | | Processing | Store-and-Forward | | Switch Latency | <7us | | Switch Bandwidth | 1Gbps | | Packet buffer size | 448K bits | | LED Indicators | | | Power Indicator | Green : Power LED x 2 | | Fault Indicator | Amber : Indicates power failure occurred | | 10/100Base-T(X) RJ45 Port Indicator | Upper for Link/Act indicator, Green for port Link/Act. Lower for speed indicator, Amber for 100Mbps, OFF for 10Mbps | | Fault Contact | | | Relay | Relay output to carry capacity of 1A at 24VDC | | Power | | | Input Power | Dual 12~48 VDC power input on 4-pin terminal block | | Power Consumption (Typ.) | 4 Watts | | Overload Current Protection | Present | | Reverse Polarity Protection | Present | | Physical Characteristics | | | Enclosure | IP-30 | | Dimensions (W x D x H) | 41 (W) x 90 (D) x 95 (H)mm (1.61 x 3.54 x 3.74 inch) | | Weight (g) | 383 g | | Environmental | | | Storage Temperature | -40 to 85°C (-40 to 185°F) | | Operating Temperature | -40 to 75°C (-40 to 167°F) | | Operating Humidity | 5% to 95% Non-condensing | | Regulatory Approvals | | | EMI | FCC Part 15, CISPR (EN55022) class A | | EMS | IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 | | Shock | IEC60068-2-27 | | Free Fall | IEC60068-2-32 | | Vibration | IEC60068-2-6 | | Safety | EN60950-1 | | Warranty | 5 years | |
| Description |
- Supports 8 ports 10/100 Base-T(X)
- Supports auto-negotiation and auto-MDI/MDI-X
- Supports store and forward transmission
- Supports flow control
- Compact size for easily installation
- Rigid IP-30 housing design
- DIN-Rail and wall mounting enabled
|
