Shop IGS-1041GPA 5-Port Ethernet Switch

Details

• Each unit supports 5 x 10/100/1000Base-T(X) ports or 4 x 10/100/1000Base-T(X) and 1 x 1000Base-X SFP ports
• Support Jumbo Frame up to 9K Bytes
• Hardware DIP switch to enable/disable warning function
• Rigid IP-30 slim type housing design
• DIN-Rail and wall mounting enabled
• Relay output to carry capacity of 1A at 24 VDC

More Information

Specifications

Physical Ports
1000Base-X SFP Ports	1
10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX	4
Technology
Ethernet Standards	IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX IEEE 802.3z for 1000Base-X IEEE 802.3ab for 1000Base-T IEEE 802.3x for Flow control
MAC Table	1024 MAC addresses
Processing	Store-and-Forward
Jumbo Frame	9K
LED Indicators
Power Indicator	Green : Power LED x 2
Fault Indicator	Amber : Indicates PWR1 or PWR2 failure occurred
1000Base-X SFP Port Indicator	Green for port Link/Act
10/100/1000Base-T(X) RJ45 Port Indicator	Green for port Link / Act Amber for 100Mbps indicator
Fault Contact
Relay	Relay output to carry capacity of 1A at 24VDC
Power
Redundant Input Power	Dual DC inputs. 12~48 VDC on 6-pin terminal block
Power Consumption (Typ.)	5.5 Watts
Overload Current Protection	Present
Reverse Polarity Protection	Present
Physical Characteristics
Enclosure	IP-30
Dimensions (W x D x H)	26.1(W) x 94.9(D) x 144.3(H) mm ( 1.03x3.74x5.68 inch.)
Weight (g)	403g
Environmental
Storage Temperature	-40 to 85°C (-40 to 185°F)
Operating Temperature	-40 to 70°C (-40 to 158°F)
Operating Humidity	5% to 95% Non-condensing
Regulatory Approvals
EMI	FCC Part 15, CISPR (EN55022) class A
EMS	IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11
Shock	IEC60068-2-27
Free Fall	IEC60068-2-32
Vibration	IEC60068-2-6
Safety	EN60950-1
Warranty	5 years

Description

• Each unit supports 5 x 10/100/1000Base-T(X) ports or 4 x 10/100/1000Base-T(X) and 1 x 1000Base-X SFP ports
• Support Jumbo Frame up to 9K Bytes
• Hardware DIP switch to enable/disable warning function
• Rigid IP-30 slim type housing design
• DIN-Rail and wall mounting enabled
• Relay output to carry capacity of 1A at 24 VDC

Reviews

Write Your Own Review

Downloads

Datasheet

IGS-1041GPA 5-Port Unmanaged Ethernet Switch
