IPGS-5416MGSFP-16 - 20 port managed PoE switch

A$0.00

In stock

SKU

IPGS-5416MGSFP-16

- Support IEEE802.3at/af up to 30W per port
- PoE management incl. Detection and Scheduling
- Enhanced G.8032 ring protection < 20ms for single ring. Supports auto mode*, enhanced mode, train mode*, multi-VLAN* and basic mode; Enhanced G.8032 ring covers multicast packets; MSTP 8/16*MSTI /RSTP ; support MRP ring**

Details

_Standards	_{IEEE802.3 10Base-T Ethernet} _{IEEE802.3u 100Base-TX} _{IEEE802.3ab 1000Base-T} _{IEEE802.3z Gigabit fiber} _{IEEE802.3x Flow Control and Back Pressure} _{IEEE802.3ad Port trunk with LACP} _{IEEE802.1d Spanning Tree} _{IEEE802.1w Rapid Spanning Tree} _{IEEE802.1s Multiple Spanning Tree} _{IEEE802.3ad Link Aggregation Control Protocol (LACP)} _{IEEE802.1AB Link Layer Discovery Protocol (LLDP)} _{IEEE802.1X User Authentication (Radius)} _{IEEE802.1p Class of Service} _{IEEE802.1Q VLAN Tag} _{IEEE802.3at/af Power over Ethernet}
_{Switch Architecture}	_{Back-plane (Switching Fabric): 40Gbps}
_{Transfer Rate}	_{14,880pps for Ethernet port} _{148,800pps for Fast Ethernet port} _{1,488,000pps for Gigabit Ethernet / Gigabit Fiber port}
_{Mac Address}	_{16K MAC address table}
_{Jumbo frame}	_10KB
_Connectors	_{10/100/1000T: 16 x ports RJ-45 with Auto MDI/MDI-X function} _{Mini-GBIC: 4 x 1G/2.5G SFP socket with DDMI} _{RS-232 connector: RJ-45 type} _{USB x 1} _{Power & Relay connector: 1 x 6-pole terminal block} _{DIDO : 1 x 6-pole terminal block}
_{Network Cable}	_{10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E/ 6 cable} _{EIA/TIA-568 100-ohm (100m)} _{100Base-TX: 2-pair UTP/STP Cat. 5/ 5E/ 6 cable} _{EIA/TIA-568 100-ohm (100m)}
_{Optical Cable}	_1Gbps: _{Multi mode: 0 to 550 m, 850 nm (50/125 μm); 0 to 2 km, 1310 nm (50/125 μm)} _{Single mode: 0 to 10 km/ 30 km/ 40 km, 1310 nm (9/125 μm); 0 to 50 km/ 60 km/ 80km/ 120 km, 1550 nm (9/125 μm)} _2.5Gbps _{Multi mode: 0 to 300 m, 850 nm (50/125 μm);} _{Single mode: 0 to 2 km/ 15 km/ 40 km, 1310 nm (9/125 μm); 0 to 40 km/ 80 km/ 100km, 1550 nm (9/125 μm)} _{WDM 1Gbps:} _{Single mode: 0 to 10 km/ 20 km/ 40 km/ 60 km, 1310 nm (9/125 μm); 0 to 80 km, 1490 nm (9/125 μm); 0 to 10 km/ 20 km/ 40 km/ 60 km/ 80 km, 1550 nm (9/125 μm)} _{WDM 2.5Gbps} _{Single mode: 0 to 5 km/ 20 km/ 40 km/ 60 km, 1310 /1550nm (9/125 μm); 0 to 80 km, 1490/1550 nm (9/125 μm)}
_LED	_{Per unit: Power 1 (Green), Power 2 (Green), FAULT (Red); RM(Green)} _{Ethernet port: Link/Activity (Green), Speed (Green);} _{PoE : Link/Act (Green); Mini-GBIC: Link/Activity (Green)}
_DI/DO	_{2 Digital Input (DI) :} _{Level 0: -30~2V / Level 1: 10~30V} _{Max. input current:8mA} _{2 Digital Output(DO): Open collector to 40 VDC, 200mA}
_{Operating Humidity}	_{5% ~ 95% (Non-condensing)}
_{Operating Temperature}	_{-20°C~60°C / -4°F~140°F (Standard model)} _{-40°C~75°C / -40°F~167°F(-E model)}
_{Storage Temperature}	_{-40°C~85°C / -40°F~185°F}
_{Power Supply}	_{44~56VDC(48V model); 9.5V~56VDC(24V model)}
_{PoE Budget}	_{240W for 44~56V input(48V model)} _{(54V input is recommended for PTZ or heater applications} _{60W at 12V input; 120W at 24V input(24V model)}
_{PoE pin assignment}	_{RJ-45 port # 1~#16 support IEEE 802.3at/af End-point, Alternative A mode.} _{Positive (VCC+): RJ-45 pin 1,2.} _{Negative (VCC-): RJ-45 pin 3,6.}
_{Power Consumption}	_21W
_{Case Dimension}	_{Metal case. IP-30,} _{95.84 (W) x 135 (D) x 152 (H) mm}
_Weight	_1.6kg
_Installation	_{DIN Rail and Wall Mount** Design}
_{EMI & EMS}	_{FCC Class A,} _{CE EN55022 Class A, CE EN55024, CE EN61000-4-2, CE EN61000-4-3, CE EN61000-4-4, CE EN61000-4-5 ED3, CE EN61000-4-6, CE N61000-4-8, EN61000-4-11}
_{Railway compliance*}	_{EN50155:2017, EN50121-3-2:2015,} _{EN50121-4:2015, EN61373:2010}
_{Stability Testing}	_{IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock),} _{IEC60068-2-6 (Vibration)}
_MTBF	_{586,057 hours}
_Warranty	_{5 years}

More Information

Description

_Standards	_{IEEE802.3 10Base-T Ethernet} _{IEEE802.3u 100Base-TX} _{IEEE802.3ab 1000Base-T} _{IEEE802.3z Gigabit fiber} _{IEEE802.3x Flow Control and Back Pressure} _{IEEE802.3ad Port trunk with LACP} _{IEEE802.1d Spanning Tree} _{IEEE802.1w Rapid Spanning Tree} _{IEEE802.1s Multiple Spanning Tree} _{IEEE802.3ad Link Aggregation Control Protocol (LACP)} _{IEEE802.1AB Link Layer Discovery Protocol (LLDP)} _{IEEE802.1X User Authentication (Radius)} _{IEEE802.1p Class of Service} _{IEEE802.1Q VLAN Tag} _{IEEE802.3at/af Power over Ethernet}
_{Switch Architecture}	_{Back-plane (Switching Fabric): 40Gbps}
_{Transfer Rate}	_{14,880pps for Ethernet port} _{148,800pps for Fast Ethernet port} _{1,488,000pps for Gigabit Ethernet / Gigabit Fiber port}
_{Mac Address}	_{16K MAC address table}
_{Jumbo frame}	_10KB
_Connectors	_{10/100/1000T: 16 x ports RJ-45 with Auto MDI/MDI-X function} _{Mini-GBIC: 4 x 1G/2.5G SFP socket with DDMI} _{RS-232 connector: RJ-45 type} _{USB x 1} _{Power & Relay connector: 1 x 6-pole terminal block} _{DIDO : 1 x 6-pole terminal block}
_{Network Cable}	_{10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E/ 6 cable} _{EIA/TIA-568 100-ohm (100m)} _{100Base-TX: 2-pair UTP/STP Cat. 5/ 5E/ 6 cable} _{EIA/TIA-568 100-ohm (100m)}
_{Optical Cable}	_1Gbps: _{Multi mode: 0 to 550 m, 850 nm (50/125 μm); 0 to 2 km, 1310 nm (50/125 μm)} _{Single mode: 0 to 10 km/ 30 km/ 40 km, 1310 nm (9/125 μm); 0 to 50 km/ 60 km/ 80km/ 120 km, 1550 nm (9/125 μm)} _2.5Gbps _{Multi mode: 0 to 300 m, 850 nm (50/125 μm);} _{Single mode: 0 to 2 km/ 15 km/ 40 km, 1310 nm (9/125 μm); 0 to 40 km/ 80 km/ 100km, 1550 nm (9/125 μm)} _{WDM 1Gbps:} _{Single mode: 0 to 10 km/ 20 km/ 40 km/ 60 km, 1310 nm (9/125 μm); 0 to 80 km, 1490 nm (9/125 μm); 0 to 10 km/ 20 km/ 40 km/ 60 km/ 80 km, 1550 nm (9/125 μm)} _{WDM 2.5Gbps} _{Single mode: 0 to 5 km/ 20 km/ 40 km/ 60 km, 1310 /1550nm (9/125 μm); 0 to 80 km, 1490/1550 nm (9/125 μm)}
_LED	_{Per unit: Power 1 (Green), Power 2 (Green), FAULT (Red); RM(Green)} _{Ethernet port: Link/Activity (Green), Speed (Green);} _{PoE : Link/Act (Green); Mini-GBIC: Link/Activity (Green)}
_DI/DO	_{2 Digital Input (DI) :} _{Level 0: -30~2V / Level 1: 10~30V} _{Max. input current:8mA} _{2 Digital Output(DO): Open collector to 40 VDC, 200mA}
_{Operating Humidity}	_{5% ~ 95% (Non-condensing)}
_{Operating Temperature}	_{-20°C~60°C / -4°F~140°F (Standard model)} _{-40°C~75°C / -40°F~167°F(-E model)}
_{Storage Temperature}	_{-40°C~85°C / -40°F~185°F}
_{Power Supply}	_{44~56VDC(48V model); 9.5V~56VDC(24V model)}
_{PoE Budget}	_{240W for 44~56V input(48V model)} _{(54V input is recommended for PTZ or heater applications} _{60W at 12V input; 120W at 24V input(24V model)}
_{PoE pin assignment}	_{RJ-45 port # 1~#16 support IEEE 802.3at/af End-point, Alternative A mode.} _{Positive (VCC+): RJ-45 pin 1,2.} _{Negative (VCC-): RJ-45 pin 3,6.}
_{Power Consumption}	_21W
_{Case Dimension}	_{Metal case. IP-30,} _{95.84 (W) x 135 (D) x 152 (H) mm}
_Weight	_1.6kg
_Installation	_{DIN Rail and Wall Mount** Design}
_{EMI & EMS}	_{FCC Class A,} _{CE EN55022 Class A, CE EN55024, CE EN61000-4-2, CE EN61000-4-3, CE EN61000-4-4, CE EN61000-4-5 ED3, CE EN61000-4-6, CE N61000-4-8, EN61000-4-11}
_{Railway compliance*}	_{EN50155:2017, EN50121-3-2:2015,} _{EN50121-4:2015, EN61373:2010}
_{Stability Testing}	_{IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock),} _{IEC60068-2-6 (Vibration)}
_MTBF	_{586,057 hours}
_Warranty	_{5 years}

Reviews

Write Your Own Review

Downloads

Product Data Sheet

IPGS-5416MGSFP-16 - 20 port managed PoE switch

Standards

Switch Architecture

Back-plane (Switching Fabric): 40Gbps

Transfer Rate

14,880pps for Ethernet port 148,800pps for Fast Ethernet port 1,488,000pps for Gigabit Ethernet / Gigabit Fiber port

Mac Address

16K MAC address table

Jumbo frame

10KB

Connectors

10/100/1000T: 16 x ports RJ-45 with Auto MDI/MDI-X function Mini-GBIC: 4 x 1G/2.5G SFP socket with DDMI RS-232 connector: RJ-45 type USB x 1 Power & Relay connector: 1 x 6-pole terminal block DIDO : 1 x 6-pole terminal block

Network Cable

10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E/ 6 cable EIA/TIA-568 100-ohm (100m) 100Base-TX: 2-pair UTP/STP Cat. 5/ 5E/ 6 cable EIA/TIA-568 100-ohm (100m)

Optical Cable

LED

Per unit: Power 1 (Green), Power 2 (Green), FAULT (Red); RM(Green) Ethernet port: Link/Activity (Green), Speed (Green); PoE : Link/Act (Green); Mini-GBIC: Link/Activity (Green)

DI/DO

2 Digital Input (DI) : Level 0: -30~2V / Level 1: 10~30V Max. input current:8mA 2 Digital Output(DO): Open collector to 40 VDC, 200mA

Operating Humidity

5% ~ 95% (Non-condensing)

Operating Temperature

-20°C~60°C / -4°F~140°F (Standard model)-40°C~75°C / -40°F~167°F(-E model)

Storage Temperature

-40°C~85°C / -40°F~185°F

Power Supply

44~56VDC(48V model); 9.5V~56VDC(24V model)

PoE Budget

240W for 44~56V input(48V model) (54V input is recommended for PTZ or heater applications 60W at 12V input; 120W at 24V input(24V model)

PoE pin assignment

RJ-45 port # 1~#16 support IEEE 802.3at/af End-point, Alternative A mode. Positive (VCC+): RJ-45 pin 1,2. Negative (VCC-): RJ-45 pin 3,6.

Power Consumption

21W

Case Dimension

Metal case. IP-30, 95.84 (W) x 135 (D) x 152 (H) mm

Weight

1.6kg

Installation

DIN Rail and Wall Mount** Design

EMI & EMS

FCC Class A, CE EN55022 Class A, CE EN55024, CE EN61000-4-2, CE EN61000-4-3, CE EN61000-4-4, CE EN61000-4-5 ED3, CE EN61000-4-6, CE N61000-4-8, EN61000-4-11

Railway compliance*

EN50155:2017, EN50121-3-2:2015, EN50121-4:2015, EN61373:2010

Stability Testing

IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock), IEC60068-2-6 (Vibration)

MTBF

586,057 hours

Warranty

5 years

Standards

Switch Architecture

Back-plane (Switching Fabric): 40Gbps

Transfer Rate

14,880pps for Ethernet port 148,800pps for Fast Ethernet port 1,488,000pps for Gigabit Ethernet / Gigabit Fiber port

Mac Address

16K MAC address table

Jumbo frame

10KB

Connectors

10/100/1000T: 16 x ports RJ-45 with Auto MDI/MDI-X function Mini-GBIC: 4 x 1G/2.5G SFP socket with DDMI RS-232 connector: RJ-45 type USB x 1 Power & Relay connector: 1 x 6-pole terminal block DIDO : 1 x 6-pole terminal block

Network Cable

10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E/ 6 cable EIA/TIA-568 100-ohm (100m) 100Base-TX: 2-pair UTP/STP Cat. 5/ 5E/ 6 cable EIA/TIA-568 100-ohm (100m)

Optical Cable

LED

Per unit: Power 1 (Green), Power 2 (Green), FAULT (Red); RM(Green) Ethernet port: Link/Activity (Green), Speed (Green); PoE : Link/Act (Green); Mini-GBIC: Link/Activity (Green)

DI/DO

2 Digital Input (DI) : Level 0: -30~2V / Level 1: 10~30V Max. input current:8mA 2 Digital Output(DO): Open collector to 40 VDC, 200mA

Operating Humidity

5% ~ 95% (Non-condensing)

Operating Temperature

-20°C~60°C / -4°F~140°F (Standard model)-40°C~75°C / -40°F~167°F(-E model)

Storage Temperature

-40°C~85°C / -40°F~185°F

Power Supply

44~56VDC(48V model); 9.5V~56VDC(24V model)

PoE Budget

240W for 44~56V input(48V model) (54V input is recommended for PTZ or heater applications 60W at 12V input; 120W at 24V input(24V model)

PoE pin assignment

RJ-45 port # 1~#16 support IEEE 802.3at/af End-point, Alternative A mode. Positive (VCC+): RJ-45 pin 1,2. Negative (VCC-): RJ-45 pin 3,6.

Power Consumption

_Standards

_{Switch Architecture}

_{Back-plane (Switching Fabric): 40Gbps}

_{Transfer Rate}

_{14,880pps for Ethernet port}
_{148,800pps for Fast Ethernet port}
_{1,488,000pps for Gigabit Ethernet / Gigabit Fiber port}

_{Mac Address}

_{16K MAC address table}

_{Jumbo frame}

_10KB

_Connectors

_{10/100/1000T: 16 x ports RJ-45 with Auto MDI/MDI-X function}
_{Mini-GBIC: 4 x 1G/2.5G SFP socket with DDMI}
_{RS-232 connector: RJ-45 type}
_{USB x 1}
_{Power & Relay connector: 1 x 6-pole terminal block}
_{DIDO : 1 x 6-pole terminal block}

_{Network Cable}

_{10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E/ 6 cable}
_{EIA/TIA-568 100-ohm (100m)}
_{100Base-TX: 2-pair UTP/STP Cat. 5/ 5E/ 6 cable}
_{EIA/TIA-568 100-ohm (100m)}

_{Optical Cable}

_LED

_{Per unit: Power 1 (Green), Power 2 (Green), FAULT (Red); RM(Green)}
_{Ethernet port: Link/Activity (Green), Speed (Green);}
_{PoE : Link/Act (Green); Mini-GBIC: Link/Activity (Green)}

_DI/DO

_{2 Digital Input (DI) :}
_{Level 0: -30~2V / Level 1: 10~30V}
_{Max. input current:8mA}
_{2 Digital Output(DO): Open collector to 40 VDC, 200mA}

_{Operating Humidity}

_{5% ~ 95% (Non-condensing)}

_{Operating Temperature}

_{-20°C~60°C / -4°F~140°F (Standard model)}
_{-40°C~75°C / -40°F~167°F(-E model)}

_{Storage Temperature}

_{-40°C~85°C / -40°F~185°F}

_{Power Supply}

_{44~56VDC(48V model); 9.5V~56VDC(24V model)}

_{PoE Budget}

_{240W for 44~56V input(48V model)}
_{(54V input is recommended for PTZ or heater applications}
_{60W at 12V input; 120W at 24V input(24V model)}

_{PoE pin assignment}

_{RJ-45 port # 1~#16 support IEEE 802.3at/af End-point, Alternative A mode.}
_{Positive (VCC+): RJ-45 pin 1,2.}
_{Negative (VCC-): RJ-45 pin 3,6.}

_{Power Consumption}

_21W

_{Case Dimension}

_{Metal case. IP-30,}
_{95.84 (W) x 135 (D) x 152 (H) mm}

_Weight

_1.6kg

_Installation

_{DIN Rail and Wall Mount** Design}

_{EMI & EMS}

_{FCC Class A,}
_{CE EN55022 Class A, CE EN55024, CE EN61000-4-2, CE EN61000-4-3, CE EN61000-4-4, CE EN61000-4-5 ED3, CE EN61000-4-6, CE N61000-4-8, EN61000-4-11}

_{Railway compliance*}

_{EN50155:2017, EN50121-3-2:2015,}
_{EN50121-4:2015, EN61373:2010}

_{Stability Testing}

_{IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock),}
_{IEC60068-2-6 (Vibration)}

_MTBF

_{586,057 hours}

_Warranty

_{5 years}
