42.0 mm x 22.0 mm x 3.58 mm (1.65" x 0.87" x 0.14")
Weight
5 g (0.18 oz)
Form Factor
M.2
M.2 Type
2242-D2-B-M
Interface
Bus Interface
SATA III 6Gb/s
Storage
Flash Type
3D TLC NAND flash
Capacity
64 GB/
128 GB/
256 GB/
512 GB
Operating Environment
Operating Voltage
3.3V±5%
Operating Temperature
Standard
0°C (32°F) ~ 70°C (158°F)
Wide Temp.
-40°C (-40°F) ~ 85°C (185°F)
Storage Temperature
-40°C (-40°F) ~ 85°C (185°F)
Humidity
5% ~ 95%
Shock
1500 G, 0.5 ms, 3 axis
Vibration (Operating)
2.17 G (peak-to-peak), 10 Hz ~ 700 Hz (frequency)
Power
Power Consumption (Operation)
1.6 watt(s)
Power Consumption (Sleep)
0.3 watt(s)
Performance
Sequential Read/Write (CrystalDiskMark, max.)
Read: 560 MB/s Write: 410 MB/s
4K Random Read/Write (IOmeter, max.)
Read: 55,000 IOPS Write: 75,000 IOPS
Mean Time Between Failures (MTBF)
2,000,000 hour(s)
Terabytes Written (Max.)
880 TB
Drive Writes Per Day (DWPD)
1.61 (3 yrs)
Note
Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Warranty
Certificate
CE/
FCC/
BSMI
Warranty
Three-year Limited Warranty
Warranty Policy
Please check https://au.transcend-info.com/Warranty for more information about the Transcend Warranty Policy.
Warranty does not apply when SSD Scope's wear-out indicator displays 0% within the warranty coverage.
Due to the complexity and variety of industrial applications, Transcend cannot guarantee 100% compatibility with all platforms and under all scenarios. For special applications and environments, it is strongly suggested that you contact Transcend beforehand for clarification.
SSD Scope Pro software is required by request. Please contact us for more information.
Description
DRAM Cache embedded
Space-saving M.2 form factor (42mm) – ideal for mobile computing devices
