OFT-07W03 7" Z8350 Open Frame Panel PC

Be the first to review this product

A$0.00

In stock

SKU

OFT-07W03-500x-A1R

7" open frame tablet

Details

7" open frame tablet

· Intel® Atom™ Processor Z3735F

· 2GB RAM

· 8GB or 32GB eMMC

· PCAP Touch

· 10/100 Ethernet (PXE Boot)

· Touch board interface (Power/ Brightness/ Volume/ LED)

· 16Bit programmable GPIO

· RS232(TX/RX) or RS485

· DC 12~24V Input

More Information

Brand

Avalue Technology Inc

Specifications

System
Processor	Intel® Atom™ Processor Z8350 1.33GHz Quad Core CPU
System Memory	2 or 4GB DDR3L RAM

Storage
Storage	32GB or 64GB eMMC

Panel
LCD Size	7"
Display Type	LCD
Resolution	1280x800
Luminance	300
Touch Type	PCAP

I/O

External I/O Connector

1 x USB2.0, 1 x USB3.0
1 x micro USB Client(Android only)
1 x 10/100 Ethernet
1 x HDMI
1 x Head phone jack
1 x Micro SD slot
1 x DC jack

Internal I/O Connector

1 x 16 bit GPIO interface
2 x USB interface
2 x speaker interface (1.2W stereo)
1 x A-MIC interface
1 x Touch Button connector
1 x DC input 4pin header
1 x I2C interface
4 x RS232, 1 x RS485

1 x M.2 for LTE / SIM

Display
Multiple Display	Windows/ Linux support extended mode; Android support clone mode only

Mechanical & Environmental
Power Requirement	DC 12~24V Input
Power Type	DC Jack,DC input 4pin header
Operating Temperature	0°C ~ 40°C
Storage Temperature	-10°C ~ 60°C
Operating Humidity	0% ~ 90% Relative Humidity, Non-condensing
Weight	0.33kg
Dimension (L x W x H)	116 x 184 x 25mm
