OPS500-501-H, 7th gen LGA1151 CPU, Intel H110
Open Pluggable Specification (OPS) Digital Signage Player with LGA1151 Socket 7th/6th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor and Intel® H110
Open Pluggable Specification (OPS) Digital Signage Player with LGA1151 Socket 7th/6th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor and Intel® H110
· Intel® Open Pluggable Specification (OPS compliance)
· 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processors (Kaby Lake/Skylake)
· DDR4-2133/2400 SO-DIMM for up to 16GB of memory
· 1 PCI Express Mini Card slot
· HDMI for 2nd ultra HD display with 4K @ 60Hz resolution
· Easy installation and maintenance
More Information
| brand |
Axiomtek |
| Specifications |
| CPU |
- LGA1151 socket 7th/6th generation Intel® Core™ and Celeron® processors
|
| Chipset |
|
| System Memory |
- 7th generation Intel® Core™:
1 x 260-pin DDR4-2133/2400 SO-DIMM, up to 16GB
- 6th generation Intel® Core™:
1 x 260-pin DDR4-2133 SO-DIMM, up to 16GB
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® i219-LM)
|
| Display |
- 1 x HDMI 1.4b with 4K resolution
|
| Audio |
- 1 x Audio (Line-out & Mic-in)
|
| JAE Connector |
- 1 x DisplayPort
- 1 x HDMI 2.0
- 2 x USB 2.0
- 1 x USB 3.0
- 1 x Audio (Line-out)
- 1 x UART (TX/RX)
|
| HRS Connector |
|
| Wi-Fi |
|
| Storage |
- 1 x 2.5" SATA HDD tray
- 1 x mSATA (optional)
|
| Expansion |
- 1 x Full-size PCI Express Mini Card (USB + PCI Express + SATA Signal)
|
| Power Supply |
- 1 x 12 VDC power input (adapter available by option)
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Operating Temperature |
- 0°C to +45°C (+32°F to +113°F) (with airflow 1.2m/s)
|
Dimensions
(W x D x H) |
- 200 x 119 x 30 mm (7.87” x 4.68” x 1.18”)
|
| Weight (net/gross) |
- 1 kg (2.21lb)/ 1.5 kg (3.3 lb)
|
| Certifications |
|
|
| Description |
Open Pluggable Specification (OPS) Digital Signage Player with LGA1151 Socket 7th/6th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor and Intel® H110
· Intel® Open Pluggable Specification (OPS compliance)
· 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processors (Kaby Lake/Skylake)
· DDR4-2133/2400 SO-DIMM for up to 16GB of memory
· 1 PCI Express Mini Card slot
· HDMI for 2nd ultra HD display with 4K @ 60Hz resolution
· Easy installation and maintenance
|
