SDXC230I - microSDHC

A$0.00

In stock

The industrial-grade microSDHC/SDXC230I cards offer wide temperature tolerance (-40°C to 85°C) for industrial use. These cards are the ideal solution for small form factor and write-intensive applications such as medical devices, surveillance systems, and POS terminals.

Details

High-quality 3D NAND flash and SLC mode for exceptional endurance and reliability

Compliant with Speed Class 10

Compliant with Video Speed Class 30 (V30)

Compliant with SD specification 3.01 (2~4GB) and 5.1 (8~64GB)

Built-in ECC (Error Correction Code) functionality

Global Wear-Leveling and Block management for reliability

Enhanced S.M.A.R.T. function for durability

Compliant with RoHS 2.0 standards

More Information

Specifications

Appearance
Dimensions	11 mm x 15 mm x 1 mm (0.43" x 0.59" x 0.04")
Form Factor	microSD flash card
Storage
Flash Type	3D NAND flash (SLC mode)
Capacity	2 GB/ 4 GB/ 8 GB/ 16 GB/ 32 GB/ 64 GB
Operating Environment
Operating Voltage	2.7V ~ 3.6V
Drop Test	1.5m free fall
Operating Temperature	Wide Temp. -40°C (-40°F) ~ 85°C (185°F)
Storage Temperature	-40°C (-40°F) ~ 85°C (185°F)
Humidity	0% ~ 95%
Shock	Acceleration: 490 m/s² (standard holding time: 11 ms, semi-sine wave, velocity change: 3.44 m/s)
Vibration (Operating)	20 G (peak-to-peak), 20 Hz ~ 2,000 Hz (frequency)
Power
Power Consumption (Max.)	0.2 watt(s)
Performance
Read Speed (Max.)	100 MB/s
Write Speed (Max.)	70 MB/s
Terabytes Written (Max.)	5,800 TBW
Note	Speed may vary due to host hardware, software, usage, and storage capacity.
Warranty
Certificate	CE/ FCC
Warranty	Three-year Limited Warranty
Warranty Policy	Please check https://au.transcend-info.com/Warranty for more information about the Transcend Warranty Policy. Due to the complexity and variety of industrial applications, Transcend cannot guarantee 100% compatibility with all platforms and under all scenarios. For special applications and environments, it is strongly suggested that you contact Transcend beforehand for clarification.
