TANK-610-BW Fanless Embedded System with AWS IoT Greengrass Qualified

A$0.00

In stock

SKU

TANK-610-BW-N3/2G-R10

Fanless wide temperature embedded system with Intel® Celeron® N3160 1.6GHz

Fanless wide temperature embedded system with Intel® Celeron® N3160 1.6GHz

● Intel® Celeron® N3160 processor

● Multiple COM ports: six RS-232 and two RS-232/422/485

● VGA and HDMI dual independent display

● mSATA and one x 2.5" SATA storage device

● Wide range temperature

Brand

IEI Integration Corp.

Specifications

Spec Item	Description
Form factor
SBC Form Factor	CPU: Intel® Celeron® N3160 processor (up to 2.24GHz, quad-core, 2MB cache, TDP=6W) Chipset:SoC System Memory: 2 x 204-pin DDR3L 1.35V SDRAM SO-DIMM (system Max : 8GB)
I/O Interface
I/O Ports	4 x USB 3.0 Ethernet: 2 x RJ-45 PCIe GbE by Intel® I210-IT COM Port: 6 x RS-232, 2 x RS-232/422/485 Display:1 x VGA, 1 x HDMI Resolution: VGA: Up to 2560 x 1600, HDMI: Up to 3840 x 2160 Audio:1 x Line-out, 1 x Mic-in Wireless:1 x 802.11 b/g/n (optional)
Expansion Slots
Expansion Slots	PCIe Mini:1 x Full size (support mSATA, co-lay SATA), 1 x Half size
System
Cooling method / System Fan	Fanless
Drive Bays	1 x 2.5' SATA 6Gb/s HDD/SSD Bay
Color
Color	Black C + Silver
Dimensions
Dimensions	184 x 200.6 x 58.2
Weight
Weight	2.2 kg/3 kg
Environment
Operating Temperature	-40°C ~ 60°C with air flow (SSD)
Humidity	10% ~ 95%, non-condensing
