IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX IEEE 802.3x for Flow control IEEE 802.1D for STP (Spanning Tree Protocol) IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol) IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)
MAC Table
1024 MAC addresses
Priority Queues
4
Processing
Store-and-Forward
Switch Properties
Switching bandwidth: 1.0Gbps VLAN: Port Based
Security Features
Enable/Disable ports VLAN to segregate and secure network traffic SNMP v3 encrypted authentication and access security
Software Feature
STP/RSTP (IEEE 802.1D/w) Redundant Ring (O-Ring) with recovery time less than 10ms over 250 units Port configuration, status, statistics, monitoring, security
Network Redundancy
O-Ring O-Chain Fast recovery STP RSTP
LED Indicators
Power Indicator
Green : Power LED x 1
Ring Master Indicator
Green : Indicate system operated in O-Ring Master mode
O-Ring Indicator
Amber : Indicate port operated in O-Ring mode (per port)
10/100Base-T(X) RJ45 Port Indicator
Green for port Link/Act. (per port)
Power
Input Power
12~ 48 VDC power input in M12 connector (A-coding)
Power Consumption (Typ.)
3 Watts
Overload Current Protection
Present
Reverse Polarity Protection
Present
Physical Characteristic
Enclosure
IP-30
Dimension (W x D x H)
88.9 (W) x 40 (D) x 178.2 (H)mm(3.5 x 1.57 x 7 inch)
Weight (g)
375g
Environmental
Storage Temperature
-40 to 85°C (-40 to 185°F)
Operating Temperature
-40 to 70°C (-40 to 158°F)
Operating Humidity
5% to 95% Non-condensing
Regulatory approvals
EMI
FCC Part 15, CISPR (EN55022) class A, EN50155 (EN50121-3-2, EN55011, EN50121-4)
