ORing's TGPS-W9082GF-MM-M12X-QS-MV-IP54, an EN50155-compliant Ethernet switch, is designed for rugged industrial applications. It features 8x10/100/1000Base-T(X) P.S.E. and 2x1000Base-SX Q-ODC ports, supporting Ethernet Redundancy protocols for fast recovery. With M12 connectors, it ensures secure connections in harsh environments, resisting vibration and shock.
The switch supports Power over Ethernet (PoE) with 8x10/100/1000Base-T(X) P.S.E. ports, delivering up to 30 watts. Operating from -40oC to 75oC, it complies with EN50155 standards. Managed through Open-Vision, it offers Web-based, Telnet, and console (CLI) configurations. The TGPS-W9082GF-MM-M12X-QS-MV-IP54 is an ideal choice for highly managed Ethernet applications, providing reliability and robust performance.
*NOTE: Centralized management is available upon request.
RS-232 in M12 connector (female A-coding). Baud rate setting: 115200bps, 8, N, 1
Power
Power consumption (Typ.)
17 Watts (PoE output not include)
Redundant Input power
72/110 (50.4-137.5) VDC on 4-pin M12 S-coding, male connector
Total PoE Output Power
95 watts Max.
Overload current protection
Present
Reverse polarity protection
Present
Protection / Certification
Safety
EN 62368-1
Physical Characteristic
Enclosure
IP-54, Iron
Dimensions (mm)
208 (W) x 89 (D) x 150 (H) mm 8.19 (W) x 3.5 (D) x 5.9 (H) inch
Weight (g)
3300 g
LED Indicators
Power Indicator (Power)
Green: Power LED x 1
Ring Master Indicator (R.M.)
Green: Indicates that the system is operating in O-Ring Master mode
O-Ring Indicator (Ring)
Green: Indicates that the system operating in O-Ring mode
Green Blinking: Indicates that the Ring is broken.
Fault Indicator (Fault)
Red: Indicate unexpected event occurred
10/100/1000Base-T(X) M12 P.S.E. Port Indicator
Left Green LED for port Link/Act indicator: On for link-up, Off for link-down, Blinking for act.
Middle Green LED for PoE enable indicator: On for PoE enabled, Off for PoE disabled.
Right Dual color LED for Ethernet speed indicator: Green LED for 1000Mbps, Amber for 100Mbps, Off for 10Mbps
1000Base-SX Q-ODC Port Indicator
Green LED for Link/Act indicator: On for link-up, Off for link-down, Blinking for act.
Technology
Ethernet Standards
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3z for 1000Base-X
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow control
IEEE 802.3ad for LACP (Link Aggregation Control Protocol)
IEEE 802.1p for COS (Class of Service)
IEEE 802.1Q for VLAN Tagging
IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol)
IEEE 802.1x for Authentication
IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)
IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.)
IEEE 802.3af PoE specification (up to 15.4 Watts per port for P.S.E.)
MAC Table
8K
Packet buffer Size
4Mbits
Priority Queues
8
Processing
Store-and-Forward
Switch Properties
Switching latency: andwidth: 20Gbps
Throughput (packet per second): 17.856Mpps@64Bytes packet
Max. Number of Available VLANs: 4095
IGMP multicast groups: 128 for each VLAN
Port rate limiting: User Define
Jumbo frame
Up to 9.6K Bytes
Security Features
Device Binding security feature
Enable/disable ports, MAC based port security
Port based network access control (802.1x)
VLAN (802.1Q) to segregate and secure network traffic
Radius centralized password management
SNMPv3 encrypted authentication and access security
Https / SSH enhance network security
Software Features
STP/RSTP/MSTP (IEEE 802.1D/w/s)
Redundant Ring (O-Ring) with recovery time less than 30ms over 250 units
TOS/Diffserv supported
Quality of Service (802.1p) for real-time traffic
VLAN (802.1Q) with VLAN tagging and GVRP supported
IGMP Snooping
IP-based bandwidth management
Application-based QoS management
DOS/DDOS auto prevention
Port configuration, status, statistics, monitoring, security
DHCP Server/Client/Relay
SMTP Client
Modbus TCP
Network Redundancy
O-Ring
O-Chain
MRP
MSTP (RSTP/STP compatible)
Warning / Monitoring System
Relay output for fault event alarming
Syslog server / client to record and view events
Include SMTP for event warning notification via email
Event selection support
Fixed Fiber Ports Number
Fiber Ports Standard
1000BASE-SX
Fiber Mode
Multi-mode
Fiber Diameter (μm)
62.5/125 µm @ 50/125 µm
Fiber Optical Connector
Q-ODC
Typical Distance (km)
0.55 Km
Wavelength (nm)
850 nm
Max. Output Optical Power (dBm)
-4 dbm
Min. Output Optical Power (dBm)
-9.5 dbm
Max. Input Optical Power (Saturation)(dbm)
0 dbm
Min. Input Optical Power (Saturation)(dBm)
-18 dbm
Link Budget (dB)
8.5 db
Fault contact
Relay
Relay output to carry capacity of 3A at 24VDC on M12 connector (5-pin A-coding, female connector)
Reset Function
Reset Button
5 sec: Factory default
Environmental
Storage Temperature
-40 to 85℃ (-40 to 185℉)
Operating Temperature
-40 to 75℃ (-40 to 167℉)
Operating Humidity
5% to 95% Non-condensing
Warranty
Warranty
5 years
Description
ORing's TGPS-W9082GF-MM-M12X-QS-MV-IP54, an EN50155-compliant Ethernet switch, is designed for rugged industrial applications. It features 8x10/100/1000Base-T(X) P.S.E. and 2x1000Base-SX Q-ODC ports, supporting Ethernet Redundancy protocols for fast recovery. With M12 connectors, it ensures secure connections in harsh environments, resisting vibration and shock.
The switch supports Power over Ethernet (PoE) with 8x10/100/1000Base-T(X) P.S.E. ports, delivering up to 30 watts. Operating from -40oC to 75oC, it complies with EN50155 standards. Managed through Open-Vision, it offers Web-based, Telnet, and console (CLI) configurations. The TGPS-W9082GF-MM-M12X-QS-MV-IP54 is an ideal choice for highly managed Ethernet applications, providing reliability and robust performance.
*NOTE: Centralized management is available upon request.
